** REST API **
The RESTful API allows developers to expand and build their apps on Plasgate. The API makes it easy to send messages to one or many destinations as well as enabling bulk messaging.
If you need to use a stateful tcp protocol (SMPP), please refer to SMPP Server API.
SMS Messages can be transmitted using the RESTful api, the following requirements must be met to enable the service:
- You need to have valid API Key, which you can generate
- You need to have balance, which you can request to topup
Send a single message
Send a single message to one destination address.
In order to deliver SMS messages, Data is transferred using HTTP POST request at the following URL:
https://cloudapi.plasgate.com/rest/sendParams:
- private_key : copy and past your private key that you generate
Header:
- X-Secret : copy and past your secret key that you generate
Body:
- JSON Data
Parameter Value/Pattern Example sender Text SMS Info to Number 85512345678 content Text Hello World There is an additional option to mask content. Place two keywords
#ma#around any text you want to mask in the content field.- The keyword
#ma#will not appear on the recipient’s device. - The masked text will be displayed as ****** in the transaction report.
- Supported multimask area.
Example
curl --location --request POST 'https://cloudapi.plasgate.com/rest/send?private_key=Private Key' --header 'X-Secret: Secret' --header 'Content-Type: application/json' --data-raw '{ "sender": "SMS Info", "to": "855123456789", "content": "Hello from rest API" }'Request with masked content
curl --location --request POST 'https://cloudapi.plasgate.com/rest/send?private_key=Private Key' --header 'X-Secret: Secret' --header 'Content-Type: application/json' --data-raw '{ "sender": "SMS Info", "to": "855123456789", "content": "Hello from rest #ma#API#ma#" }'The recipient’s device will get the message as
Hello from rest APIandHello from rest ***will be displayed in the transaction report in this situation.Send multiple messages
Send multiple messages to one or more destination addresses.
In order to deliver SMS messages, Data is transferred using HTTP POST request at the following URL:
https://cloudapi.plasgate.com/rest/batch-sendParams:
- private_key : copy and past your private key that you generate (To get private_key Click here)
Header:
- X-Secret : copy and past your secret key that you generate (To get X-Secret Click here)
Body:
- JSON Data
Parameter Example(s) Description messages [{“to”: ["85512345678", "85597123456"], “content”: “Hello World”}] Require globals {“sender”: “SMS Info”} Require batch_config {“callback_url”: “ http://example.com/callback”, “schedule_at”: “2021-09-30 09:00:00”}Optional Example
curl --location --request POST 'https://cloudapi.plasgate.com/rest/batch-send?private_key=Private Key' --header 'X-Secret: Secret' --data-raw '{ "globals": { "sender": "SMS Info" }, "messages": [ { "to": ["855123456780", "855123456781"], "content": "Hello from rest API" } ] }'For more example, please visit +Gate REST API document!
** HTTP API **
This document is targeted at software designers/programmers wishing to integrate SMS messaging as a function into their applications using HTTP protocol, e.g. in connection with WEB-server, unified messaging, information services etc…
If you need to use a stateful tcp protocol (SMPP), please refer to SMPP Server API.
SMS Messages can be transmitted using HTTP protocol, the following requirements must be met to enable the service:
You need a Plasgate user account You need sufficient credit on your user account
Sending
In order to deliver SMS messages, Data is transferred using HTTP POST request at the following URL:
https://cloudapi.plasgate.com/api/sendParameter Value / Pattern Example(s) to Destination address (required) 855 sender Originating address (required) SMS Info username Plasgate account login email example@email.com password Account password Str0ng3P@$$W0rd dlr yes or no yes dlr_url HTTP(s) callback URL (optional) http://example.com/callback dlr_level 1, 2 or 3 2 dlr_method GET or POST GET content Text Hello world ! Example
curl --location --request POST 'https://cloudapi.plasgate.com/api/send' --form 'to="855123456789"' --form 'sender="SMS Info"' --form 'content="Hello from +Gate SMS Cloud"' --form 'username="example@email.com"' --form 'password="Str0ng3P@$$W0rd"'For more example, please visit +Gate HTTP API document!
** SMPP API **
This document is targeted at software designers/programmers wishing to integrate SMS messaging through a stateful tcp protocol SMPP v3.4, if you feel this does not fit your needs and that you are more “web-service-guy” then you still can try HTTP o REST API.
SMS Messages can be transmitted using SMPP protocol, the following requirements must be met to enable the service:
You need a Plasgate user account You need sufficient credit on your Plasgate user account
Binding to SMPP Server
Using a proper SMPP Client application, the following parameters must be considered:
Parameter Value / Pattern Example(s) username Text (30 char. max) pg_smpp (To get username & password, Click here! ) password Text (30 char. max) pg_smppppwd bind cloudsmpp.plasgate.com The SMPP Server API listener will only bind to this specified address, given cloudsmpp.plasgate.com the listener will bind on all interfaces. port 2775 The binding TCP port. Supported SMPP PDUs
Plasgate SMPP Server is supporting the following PDUs:
- bind_transmitter
- bind_transceiver
- bind_receiver
- unbind
- submit_sm
- deliver_sm
- enquire_link
Example
Download the following library:
How to run the example
- Credential and content
- In
sendsms.php, on line 17$smpp->bindTransmitter(“test1khsmpp”, “Test@018”): - replace
test1khsmppwith your SMPP username - replace
Test@018with your SMPP password - On line 25, change
$messagevariable to your own content.
- Install dependencies
In the root directory run
composer install(make sure compose is ready installed on your PC).- Send SMS
php sendsms.php
